Network / force-directed graph layer (sugar)

Creates a network visualization from a nodes table (main data) plus an edges table. Equivalent to the pipeline as_graph() |> layout_force()/layout_circle() |> mark_point(data = ~nodes) |> mark_rule(data = ~edges) – the composite form exists so common network plots stay one-call simple. The laid-out graph is stored on @graph, so subsequent marks can reference ~nodes / ~edges directly, and layers/scales/theme added before this call are preserved (additive composition).

Usage

mark_network(
  plot,
  edges = NULL,
  encode_edges = NULL,
  layout = c("auto", "circle", "manual"),
  seed = NULL,
  edge_color = ._MARK_STYLE$faint,
  edge_width = ._MARK_STYLE$lw_thin,
  edge_alpha = NULL,
  edge_shape = c("straight", "curved"),
  node_color = ._MARK_STYLE$primary,
  node_size = 5,
  show_labels = TRUE,
  ...
)

Arguments

plot: A plotit object. The data should be a data.frame of nodes whose first column is a unique id.
edges: A data.frame of edges with literal source/target columns, or mapped through encode_edges.
encode_edges: An encode() object with source (required), target (required), value (optional magnitude). Visual channels supported on edges: colour/linewidth/linetype/alpha, referenced against original edge columns.
layout: Layout algorithm: "auto" (force-directed), "circle", or "manual" (numeric x/y columns on the nodes table).
seed: Random seed for the force layout (reproducibility).
edge_color: Default edge colour when no edge colour channel is mapped (default ._MARK_STYLE$faint = "grey70").
edge_width: Default edge width when no edge linewidth channel is mapped (default ._MARK_STYLE$lw_thin = 0.5).
edge_alpha: Optional alpha transparency for edge segments. NULL (default) leaves the edges fully opaque – unlike the area bands of sankey/chord, thin strokes do not need translucency; the parameter exists so the unified edge vocabulary (edge_color/edge_width/edge_alpha) is available on every relational sugar.
edge_shape: "straight" (default) renders each edge as a rule; "curved" renders quadratic-bezier links through mark_curve(), reducing visual overlap in dense networks. Curve tension is tunable via curvature in ....
node_color: Default node colour, applied to the colour and fill channels only where they are not mapped (default ._MARK_STYLE$primary = "#4E79A7").
node_size: Default node size when size is not mapped (default 5).
show_labels: If TRUE (default), draw node labels when a global label aesthetic is mapped.
...: Other arguments passed to the edge segment layer (e.g. arrow).

Value

Modified plotit object; @graph holds the laid-out tables.

Details

Fully self-contained: the force/circle layouts run on plotit's own deterministic engines and rendering is plain ggplot2 layers. Edges render as straight segments; curved edges are a known limitation of the sugar form. Mapped node colour/fill channels ship with the curated token palette (friendly qualitative / viridis sequential, chain scale_color() to replace).

References

AntV G2: ForceGraph

Examples

nodes <- data.frame(
  name  = c("A", "B", "C", "D"),
  group = c("X", "Y", "X", "Y"),
  value = c(10, 20, 15, 25)
)
edges <- data.frame(
  source = c("A", "A", "B", "C"),
  target = c("B", "C", "C", "D"),
  value  = c(1, 2, 3, 4)
)
nodes |>
  plotit(encode(color = group, size = value, label = name)) |>
  mark_network(edges = edges, seed = 1) |>
  scale_color(range = "viridis") |>
  scale_size(range = c(5, 20))
#> Scale for colour is already present.
#> Adding another scale for colour, which will replace the existing scale.
